1 With high quality optical components, providing sharp and striking contrast image and ensure flat image at big depth of field.
2 Ease the tiredness with ergonomic design
3 With LED light for both incident and transmitted illumination, providing even illumination and life expectancy can reach 6000 hours
4 With complete eyepieces, objectives and accessories, it is an ideal instrument for industry assembling, inspection and teaching field.
|
Viewing head |
45°inclined, Binocular viewing head |
|
Eyepiece |
Extra wide field eyepiece EW10X/22 |
|
Interpupillary distance |
55-75mm |
|
Magnification |
0.8-5 zoom objective |
|
Objective |
1x |
|
Working distance |
115mm |
|
Zoom ratio |
6.3:1 |
|
Stage insert |
Opal and black acrylic plate, Diameter 100mm, glass plate, Diameter 100mm |
|
illumination |
Incident illumination 100V-240V, LED |
|
Transmitted illumination 100V-240V,LED |
|
Viewing head |
60°inclined, Binocular viewing head |
|
45°inclined, Trinocular viewing head |
|
|
45°inclined, Digital viewing head |
|
|
Eyepiece |
WF15X/16 |
|
WF20X/12 |
|
|
WF30 |
|
|
Objective |
0.5X WD:220mm |
|
0.7X WD:125mm |
|
|
2X WD:45mm |
