Items

Specification

MOB-301

MOB-302

Optical System

Infinity Independent Plan Achromatic Optical System F=200mm

●

●

Viewing Head

Siedentopf binocular tube, Interpupillary distance 52~

75mm, 30°inclined, 360° rotateable, diopter adjustable.

●

Siedentopf trinocular tube, Interpupillary distance 52~

75mm, 30°inclined, trinocular light is split 20/80 by a high quality prism, diopter adjustable.

●

Binocular, Interpupillary distance 48-75mm

Trinocular, Interpupillary distance 52-75mm (100:0)

Trinocular, Interpupillary distance 48-75mm (20:80)

Trinocular, Interpupillary distance 52-75mm (50:50)

Eyepiece

WF10X/20mm, High eye-point up to 21mm.

●●

●●

High eye-point plan eyepiece  WF10X/22

Plan eyepiece  WF16X/13

High eye-point plan eyepiece  WF10X/20 (Pointer)

High eye-point plan eyepiece  WF10X/22 (Pointer)

Reticule Eyepiece, Cross  WF10X/20

Nosepiece

Quadruple, inward

●

●

Objectives

Infinity Achromatic Objective 4X N.A.0.13

Infinity Achromatic Objective 10X N.A. 0.30

Infinity Achromatic Objective 40X(S) N.A.0.70

Infinity Achromatic Objective 100X(S)/(Oil) N.A. 1.25

Infinity Plan Achromatic Objective (Economical) 4X N.A.0.13

Infinity Plan Achromatic Objective (Economical) 10X N.A.0.30

Infinity Plan Achromatic Objective (Economical) 40X(S) N.A.0.70

Infinity Plan Achromatic Objective (Economical) 100X(S) (oil) N.A.1.25

Infinity Plan Achromatic Objective 2X

Infinity Plan Achromatic Objective 4X

●

●

Infinity Plan Achromatic Objective 10X

●

●

Infinity Plan Achromatic Objective 20X

Infinity Plan Achromatic Objective 40X (S)

●

●

Infinity Plan Achromatic Objective 60X (S)

Infinity Plan Achromatic Objective 100X (S) (Oil)

●

●

Stage

Double Stage: 156×138mm platform, with X/Y travel of 76×54mm by low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide.

●

●

Rackless Stage, right handed, 185X177mm, movement range 75X50mm

Condenser

Abbe condenser: NA=1.25, with iris diaphragm, with socket to accommodate PH-slide. Condenser center adjustable, color-coded diaphragm scale markings cooresponded with the objectives of different powers.

●

●

Focusing

Coaxial coarse and fine focusing knob, height adjustable.

●

●

Electrical Parts

6V/20W Halogen Bulb: Input: 100~240V 0.5A, 47~63Hz, Output: 6V 3.4A, Fuse: 3.15A, 250V, FΦ5×20mm, Halogen Bulb Socket: G4

●

●

C-Mount

1X

●

Filter

Blue

●

●

Filter Holder

Filter Holder: (Attached to the Kholer) for more than one filter.

●

●

Illumination

6V 20W Osram Halogen Bulb

●

●

With field diaphragm (inside Kohler)

●

●

Immerse Oil

8ml

●

●

Allen Screw Driver

Φ2mm

●

●

Power Line

1.8m

●

●

Viewing Head

Siedentopf binocular tube, Interpupillary distance 48~

75mm, 30°inclined, 360° rotateable, diopter adjustable.

Siedentopf trinocular tube, Interpupillary distance 48~ 75mm, 30°inclined,trinocular light is split 20/80 by a high quality prism,diopter adjustable.

eyepieces

WF10X/22mm, High eye-point up to 21mm.

WF16X/14mm

WF10X/20mm (Pointer), High eye-point up to 21mm.

WF10X/22mm (Pointer), High eye-point up to 21mm.

Reticule Eyepiece: CROSSWF10X/20mm

Reticule Eyepiece: CROSSWF10X/22mm

Centering Telescope

CTE

Nosepiece

quintuple, inward

Objectives

Plan Achromatic 2X/0.06, WD=3.55mm

Plan Achromatic 20X/0.40, WD=2.71mm

Plan Achromatic 60X/0.80(S), WD=0.69mm

Phase-Contrast (positive or negative) Objectives

PH Plan Achromatic 10X/0.25, WD=5.03mm

PH Plan Achromatic 20X/0.40, WD=2.71mm

PH Plan Achromatic 40X/0.65, WD=0.72mm

PH Plan Achromatic 60X/0.80, WD=0.69mm

PH Plan Achromatic 100X/1.25(S,O), WD=0.17mm

Phase-Contrast Slide

10X PH

20X PH

40X PH

60X PH

100X PH

Stage

Rackless Mechanical Stage: 179(205)×175mm platform, with X/Y travel of 75×50mm by low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide.

Refocus double Stage: 156×138mm platform, with X/Y travel of 76×54mm by low-positioned X/Y coaxial control knob, with scale mark and specimen-slide clip, enough space to hold 2 specimen-slide.

Condenser

Multi-Purpose Phase contrast Condenser: NA:1.25, Phase contrast observation from 10X to 100X and Dark-field observation from 10X to 40X is allowed

Dark Condenser(Dry)

Electrical Parts

6V/30WHalogen Bulb： Input: 100~240V 0.5A, 47~63Hz, Output: 6V 3.4A, Fuse:3.15A, 250V, FΦ5×20mm, Halogen Bulb Socket: G4

3W LED Bulb

C-Mount

0.25X

0.5X

Digital Camera Adapter

(Please advice your digital camera model in advance)

Filter

Green

Yellow

Grass Glass

Polarization kits

Analyzer Slide

Polarizer Slide

Fluorescence Attachment

Hg Fluorescence Lamp house 100W

Mercury lamp 100W (Made in China)

Mercury lamp 100W (Osram)

Filter Turret

UV Shield

Hg Power Source House 100W

UV Excitaion Filter (I Grade)

V Excitation Filter (I-Grade)

B Excitation Filter (I-Grade)

G Excitation Filter (I-Grade)

UV Excitaion Filter (C-Grade)

V Excitation Filter (C-Grade)

B Excitation Filter (C-Grade)

G Excitation Filter (C-Grade)

Illumination

6V 30W Osram Halogen Bulb

3W LED Bulb

Two sides LED (3W Each side;4pcs each side;0.1w each pcs)
